FEATURES
INDUSTRY-LEADING LASER SOURCE
– This machine enjoys stable and dependable operation with a working life of over 100,000 hours thanks to its world-famous JPT laser source.
GALVO SCANNER
– Sino-Galvo SG2206 is an upgrated version of the cheaper SG7110 and better suited for a higher powered machine like this. The SG2206 scanner provides a maximum marking speed of 6000 mm/s.
LIGHTBURN COMPATIBLE
– This EzCad2-based laser works with LightBurn’s latest galvo functionality on Windows, MacOS, and Linux systems to let you create even the most intricate patterns easily.
RED LINE FOCUS ASSIST
– We upgraded from red dots to red lines – and now there is one assist installed for each lens ordered. The external lasers allow you to quickly find the correct height to start working with. Much easier than the older style red dots. To see these in action please visit our Instagram account (TheFinnlaser).
SAFE & SECURE
– With no extra cost we offer the option to have an access key to turn on your laser. The access key prevents any unauthorized use of your laser. A very good choice for families with small children.
ROTARY COMPATIBLE
– Our engraver comes with built-in support for rotary attachments with 4-pin connectors. Enjoy plug and play engraving of rings, bracelets, cups, tubes, and other cylindrical surfaces.
2-YEAR WARRANTY
– Don’t worry! We offer a 2-year warranty on this machine and a life-long support network.
• FDA Compliant• CE Certification
• ISO9001 Quality Certification
| Components & Technical Specification | |
| Max working area | 15.7"x15.7" (400*400mm) |
| Laser source | 200W JPT MOPA Laser YDFLP-E2-200-M7-M-R |
| Software | EZCAD2 Compatible with LightBurn |
| Lenses included | Choose 2 |
| Wavelength | 1064nm |
| Frequency | 1 - 4000kHz |
| Pulse duration | 2-500 ns |
| Repeated Precision | ±0.002mm |
| Galvanometer | Sino-Galvo |
| Control Card | BJJCZ Control Board |
| Warranty | 2 year |
